UH3233 Aten USB-C Dual-HDMI Mini Dock

£109.00 inc VAT

The Aten UH3233 USB-C Dual HDMI Mini Dock transforms your USB-C device to a dual monitor workstation. It is USB 3.1 compliant ans supports dual display mode and 4K (UHD) resolution. It is a plug & play with no driver or external power adapter needed.

Data Sheet

Manual

SKU: UH3233 Categories: , , , Tags: , , ,

Description

The ATEN UH3233 is a USB-C Dual-HDMI Mini Dock which transforms your USB-C device to a dual monitor workstation. It’s compliant with the latest USB 3.1 Type-C specifications and supports dual display mode. The UH3233 can route video from the source device to two HDMI monitors, splitting the video transmission for a dual-view display via a single cable while maintaining a high quality resolution up to 1080p.

The UH3233 uses USB-C connections to deliver reliable highspeed data transfers. You can connect up to 128 additional peripherals, including Dual HDMI and USB 3.1 Gen1 devices. The UH3233’s slim and light design makes it ideal to maximize your workspace and travel with for business on the go.

Features

  • USB 3.1 Gen1 compliant
  • Connects a computer to two HDMI monitors with Dual-View output
  • Supports 4K (UHD) resolutions via single display output*
  • Supports dual-display video output up to 1920 x 1080 simultaneously**
  • USB 3.1 Gen1 port with data transfer rates up to 5 Gbps
  • Plug and Play – no drivers or external power adapter needed* For video output to work through a USB-C port, it must support DP Alt Mode.
    ** For Dual-View to work, a computers graphics card must support MST technology. Mac computers only support single-view output.

Specifications

puter Connections 1
Connectors
Computer 1 x USB-C Female (Black)
Device 1 x USB3.1 Gen1 Type-A Female (Blue)
Video Output 2 x HDMI Female (Black)
LEDs
Power 1 (Blue/Orange)
Video Resolution Single View:
HDMI – 3840*2160@30*

Dual View:
HDMI – 1920*1200@60**

* For video output to work through a USB-C port, it must support DP Alt Mode.
**For Dual-View to work, a computers graphics card must support MST technology. Mac computers only support single-view output.Power ConsumptionDC5V , 15WPackage Contents1 x 1m USB-C CableEnvironmentalOperating Temperature0–40°CStorage Temperature-20–60°CHumidity0–80% RH, Non-condensingPhysical PropertiesHousingPlasticWeight0.10 kg ( 0.22 lb )Dimensions (L x W x H)9.37 x 9.30 x 2.68 cm
(3.69 x 3.66 x 1.06 in.)NoteFor some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format.

Package Contents

  • 1x UH3233 USB-C Dual-HDMI Mini Dock
  • 1x USB-C to USB-C Cable
  • 1x User Instructions
