SY-HDBT-662 S Y Electronics Two Zone Multi-Format HDBaseT DA Matrix Switch

£1,598.00 inc VAT

The SY Electronics SY-HDBT-662  is a six input distribution amplifier with 4 x HDMI, 1 x DisplayPort and 1 x VGA inputs and dual output zones, each providing a local HDMI output and three HDBaseT outputs. The input source for these zones can be independently selected from either the front panel buttons using RS232 commands or the Ethernet port. Full control: RS232, Ethernet, and IR control with separate RS232 port for the HDBaseT outputs and IR control to or from the remote location via the HDBaseT outputs.   If you need help, please call us on 01372 450 794

User Manual

Description

The SY- HDBT-662 is a six input distribution amplifier with 4 x HDMI, 1 x DisplayPort and 1 x VGA inputs and dual output zones, each providing a local HDMI output and three HDBaseT outputs. The input source for these zones can be independently selected from either the front panel buttons using RS232 commands or the Ethernet port.

  • Multi-Format Hub
    Choose from VGA, DisplayPort or HDMI sources.
  • Independent Outputs
    Each independent output is designed to extend the transmission of up to 3 displays.
  • Transmit 4K up to 70m
    Choose a number of SY’s extenders to transmit 3840×2160 8bits 30Hz up to 70m.
  • Full control
    RS232, Ethernet, and IR control with separate RS232 port for the HDBaseT outputs and IR control to or from the remote location via the HDBaseT outputs.
  • Advanced EDID management
    Ensure accuracy, superior refresh rates and instantly solve incompatibility issues with EDID control via web GUI.
  • Audio De-embedder
    Use Phoenix connectors to output analogue L+R.
  • Front Panel
    Illuminated front panel buttons for each input and output combination.
  • HDCP support
    HDMI input 1 supports HDCP 2.2.
  • 1 VGA Input
  • 1 Display Port Input
  • 4 HDMI Inputs
  • 2 Output Zones each with 1 HDMI and 3 HDBaseT Outputs
  • RS232 Control
  • Bi-directional RS232
  • IR In and Out
  • HDBaseT Output
  • 48V DC Power
  • PoC (Power over Cable) to receiver
  • HDMI 1.4
  • HDCP 1.4
  • Max resolution 4K UHD
  • Data rate 10.2 Gbps
  • Illuminated buttons indicate selected input signal
