SM-MST-2D 2-Port Dual-Head DP MST KVM Switch with USB 2.0 & Audio

SM-MST-2D Smart-AVI 2-Port Dual-Head DP MST KVM Switch with USB 2.0 & Audio

£399.00 inc VAT

Smart-AVI SM-MST-2D 2-port Dual Head usb & DP KVM switch with resolutions up to 4K UHD (3840 x 2160 @ 30Hz) per display, DisplayPort1.2a dual mode receiver, supports HDMI/DVI operation up to 320MHz with a max video input resolution 4K2K@60Hz. The switch features Multi-Stream Transport that supports up to 2 streams, supports RGB or YCbCr, balanced speakers output and switching with front panel tactile buttons with LED indicator and an external power supply – Level VI efficiency

Data Sheet

Manual

Quick Start Guide

SKU: SM-MST-2D Categories: , , , , , , , , , , , , , , , Tags: , , , ,

Description

The Smart_AVI  SM-MST-2D is a2-port Dual-Head DisplayPort MST KVM switch with USB 2.0 and audio. It is made in the USA and TAA compliant and suitable for industrial operations, defense application, corporate communication, server operations, educational administrations, Medical facilities, banking network, insurance Data Centres, transit management and intelligence communications

SM-NST-2D Features:

  • Supports Windows 7 and Windows 10
  • Single-head DP to dual-head HDMI video interface for each connected computer
  • Resolutions up to 4K UHD (3840 x 2160 @ 30Hz) per display
  • DisplayPort1.2a dual mode receiver
  • HDMI/DVI operation up to 320MHz
  • Max video input resolution 4K2K@60Hz
  • Multi-Stream Transport supports up to 2 streams
  • Supports RGB or YCbCr
  • Supports balanced speakers output and switching
  • Front panel tactile buttons with LED indicator
  • External power supply – Level VI efficiency



VIDEO
Format DisplayPort 1.2a
Input Interface (2) DisplayPort
Output Interface (2) HDMI
Input Resolution Up to 4K (3840X2160 @60Hz)
Output Resolution Up to 4K (3840X2160 @30Hz)
DDC 5 volts p-p (TTL)
Input Equalization Automatic
Input Cable Length Up to 20 ft.
Output Cable Length Up to 20 ft.
USB
Input Interface (2) USB Type B
Output Interface (2) USB 1.1 Type A for KM Devices
Emulation USB 1.1 and USB 2.0 Compatible
AUDIO
Audio Input (2) 3.5mm stereo audio
Audio Output (1) 3.5mm stereo audio
CONTROL
Front Panel Push Buttons with LED Indicators
RS-232 Via Control @ 9600 bps
Hot Keys Via Keyboard
OTHER
Power External 100-240 VAC/ 12VDC2A
@ 24W
Dimensions 8.8” W x 2.63” H x 6.69” D
Weight 3.85 lbs
Approvals UL, CE, ROHS Compliant
Operating Temperature +32 to +104°F (0 to +40°C)
Storage Temperature -4 to 140°F (-20 to +60°C)
Humidity Up to 80% (No Condensation)
