HD-EX354K Newlink HDMI up to 70m HDBaseT Extender Over CATx

The NewLink HD-EX354K HDMI HDBaseT up to 70m over CATx extender implements HDBaseT extension technology using only one Cat 5e / 6 / 6a / 7 cable to connect the transmitter and receiver and supports resolutions of up to Ultra HD 4kx2k and 1080p Full HD and up to 340MHz bandwidth for high performance video. It features Anti-jamming that  resists signal interference during high-quality video transmission using HDBaseT technology.

Description

The HD-EX354K HDMI HDBaseT Extender enables an HDMI display to be located up to 70 metres away from the source device. It can conveniently be extended using only one Cat5e / 6 / 6a / 7 cable, which is cost-effective.

HD-EX354K not only supports HDMI (3D, Deep Colour) but also Ultra HD (4k x 2k) and is HDCP compatible. It is perfect for the meeting room, home theater or any installation that needs long distance transmission and superior video quality.

HD-EX354K Features:

  • Extends the distance between HDMI source and HDMI display
  • Implements HDBaseT extension technology using only one Cat 5e / 6 / 6a / 7 cable to connect the transmitter and receiver
  • HDMI (3D, Deep Colour, 4kx2k); HDCP Compatible
  • Anti-jamming – resists signal interference during high-quality video transmission using HDBaseT technology
  • Supports resolutions of up to Ultra HD 4kx2k and 1080p Full HD
  • Supports up to 340MHz bandwidth for high performance video
  • Signaling rates up to 3.4 Gbits
  • Supports Dolby True HD and DTS HD Master Audio
  • Built-in 8KV / 15KV ESD protection (Contact voltage 8KV; Air voltage 15 KV)
  • Support 20-60kHz wide frequency devices and Bi-directional IR transmission.
  • Power consumption: TX: <3.5W; RX <6W
  • Product dimension: 98.5(L)*96.5(W)*23(H) mm

HD-EX354K:

Using Cat5e / Cat6
• 60m for up to 1080P @ 60Hz 36bpp
• 35m for 1080p @ 60Hz 48bpp
1080P @ 60Hz 3D
4kx2k @ 30Hz

• Using Cat6a / Cat7
• 70m for up to 1080P @ 60Hz 36bpp
• 40m for 1080P @ 60Hz 48bpp
1080P @ 60Hz 3D
4kx2k @ 30Hz
