EA1240 Aten PDU Temperature and Humidity Sensor

£119.00 inc VAT

Aten EA1240 Temperature and Humidity sensor works in tandem with the Power Distribution Units, which enable you to get readings of temperate and humidity. Environmental conditions can be monitored with alarms according to customizable minimum/maximum thresholds set for temperature and humidity. It features high sensitivity and a compact design with built-in 3m cable.

Description

For environmental monitoring and management, ATEN provides EA1240 sensor probes that work in tandem with the Power Distribution Units, which enable you to get readings of temperate and humidity. Environmental conditions can be monitored with alarms according to customizable minimum/maximum thresholds set for temperature and humidity.

*The EA1240 sensor is an optional accessory. You can use the ATEN PDU without environmental sensors. However, if you want to have complete energy management of your data center with the full use of ATEN solutions, a sensor installation is required.

  • Measurement range:  – °C (Temperature); 30 – 80 % RH (Humidity)
  • Measurement accuracy: +/- 1°C (Temperature); +/- 3 % RH (Humidity)
  • Compact design – built in 3m cable
  • High sensitivity
Connectors RJ-11 Male
Temperature Measurement Range 0 – 40°C
Accuracy +/- 1°C
Humidity Measurement Range 30– 80% RH
Accuracy +/- 3 % RH
Supply Voltage 5VDC (Max.)
Current Consumption 5mA max: (2mA avg.)
Environment Operating Temp. 0 – 55°C
Storage Temp. -20 –  70°C
Humidity < 95% RH
Housing Plastic
Weight 0.06 kg
Cable Length 3 meter

  • 1x EA1240 Temperature & Humidity sensor
  • 1x Sensor mount
  • 4x Tie wrap
  • 3x Adhesive cable tie holder
