CV211 Aten Laptop USB Console Adapter

Aten CV211 is a USB Console Adapter for direct laptop-to-computer remote access and provides bi-directional file transfer between the laptop and target computer. The CV211 supports analogue video resolution up to 1920 x 1200 @60Hz. Virtual media enables file applications, OS patching, software installation and diagnostic testing. Video recording and image capture feature saves a record of remote operations for future training and troubleshooting. BIOS level access – gets you into a server’s BIOS during hardware and operating system failures. No Longer Available. Please See CV211CP.

Data Sheet

Manual

SKU: CV211 Categories: Console Drawers, Converters, Converters & Adapters, KVM Switches & Extenders, Special Promotions Tags: Console Drawer, Converters and Adapters

Description

Description

Laptop USB Console Adapter
CV211

‘Turn your laptop into a mobile console in a few seconds.’ The CV211 Laptop USB Console Adapter provides a direct Laptop-to-Computer connection for fast and easy remote desktop access with no software to install. High efficiency in a compact design, the CV211 offers bi-directional file transfers, hotkey macros, video recording and screenshots through a USB 2.0 and VGA composite cable.

The innovative virtual media function provides file application, OS patching and software installations, as well as diagnostic testing through the CV211’s intuitive graphical user interface (GUI) which provides easy operation and fast remote access. The GUI console window can be adjusted to the exact size and resolution of the remote computer’s desktop by re-sizing the pane automatically; or you can manually adjust the window size as you see fit. This allows you to view the server’s entire desktop without needing to use a scroll bar.

In addition, the unique cable clip design is utilized for easy tidying up of disorganized cables while the CV211 is being used and transported. The CV211 is recommended as a portable direct connect server access troubleshooting device for IT professionals.

Features

USB Console Adapter for direct Laptop-to-Computer remote access
Bi-directional file transfers between the laptop and target computer
Supports analogue video resolutions up to 1920 x 1200 @ 60 Hz
Virtual media enables file applications, OS patching, software installation and diagnostic testing
Video recording and image capture feature saves a record of remote operations for future training and troubleshooting
BIOS level access – gets you into a server’s BIOS during hardware and operating system failures
Mouse DynaSync™ – automatically synchronizes the laptop and target computer’s mouse movements
On-screen keyboard with multi-language support
Supports hotkey macros – define keystrokes that execute specific actions on the target computer to complete tasks efficiently and accurately
Toolbar helps users easily operate all the functions from a single-click control panel within the remote view window
Desktop scaling – user can adjust the size/resolution of the Remote desktop window by size or ratio
Supports hot-plugging
Plug-and-Play – no software installation required
Firmware upgradable
Unique cable clip design to get cables under control

Specifications

Computer Connections	1
Connectors
Laptop USB Console (LUC) Port	1 x Mini-USB Female (Black)
KVM (Computer) Ports	1 x USB Type A Male (Black) 1 x VGA Male (Blue)
LEDs	1 (Blue)
Environmental
Operating Temperature	0 – 40°C
Storage Temperature	-20 – 60°C
Humidity	0 – 80% RH, Non-condensing
Physical Properties
Housing	Plastic
Weight	0.13 kg ( 0.29 lb )
Dimensions (L x W x H)	7.05 x 5.37 x 3.01 cm (2.78 x 2.11 x 1.19 in.)
Note	For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format.
