CS1764A Aten 4-Port USB 2.0 DVI KVMP Switch Bundle

£229.00 inc VAT

Aten CS1764A is a 4-port USB & DVI KVMP switch with a 2port USB 2.0 built-in hub. It features power on detection and will automatically switch to the next powered-on-computer. It is supplied all necessary cables to connect 4 USB & DVI computers.

Data Sheet

Manual









SKU: CS1764A Categories: , , , , , , , , , , , , , , , Tags: , , , ,

Description

The Aten  CS1764A is a 4-port USB and DVI KVMP switch with superior video resolution of 1920 x 1200 at 60Hz. It supports DC2B and DVI digital and analoge monitors.

The CubiQ™ CS1764A USB 2.0 DVI KVMP™ Switch charts a revolutionary new direction in KVM (Keyboard, Video, Mouse) switch functionality by combining a 4 port KVM switch with a 2 port USB 2.0 hub at the same time as it provides an interface for a digital monitor (DVI).

In addition, the CS1764A comes with ATEN’s new Video DynaSync™ technology, which optimizes display resolution, and power on detection, which means if one computer is powered off, the CS1764A will automatically switch to the next powered-on computer.
As a KVM switch, it allows users to access four computers from a single USB keyboard, USB mouse, and monitor console. As a USB 2.0 hub, it permits each computer to access any peripherals connected to the hub on a ‘one computer at a time’ basis.

  • One USB console controls four DVI computers and two additional USB 2.0 devices
  • 2-port USB 2.0 hub built in
  • Fully compliant with the USB 2.0 specification
  • Computer selection via front panel pushbuttons and hotkeys
  • Audio enabled – full bass response provides a rich experience for 2.1 channel surround sound systems
  • Multiplatform support – Windows, Linux, Mac and Sun
  • Superior video quality – 1920 x 1200, 60Hz; DDC2B
  • Independent switching of KVM, USB, and Audio focus
  • DVI digital and analog monitor support – fully compliant with the DVI specifications
  • HDCP compliant
  • Video DynaSync™ – stores the console monitor’s EDID (Extended Display Identification Data) to optimize display resolution
  • Power on detection – if one computer is powered off, the CS1764A will automatically switch to the next powered-on computer
  • Console mouse port emulation/bypass feature supports most mouse drivers and multifunction mice
  • Sun /Mac keyboard support and emulation*
  • Auto Scan Mode for monitoring all computers
  • Firmware upgradable via USB* 1. PC keyboard combinations emulate Sun/Mac keyboards
    2. Sun/Mac keyboards only work with their own computers
Computer Connections 4
Port Selection Front Panel Pushbuttons; Hotkey
Connectors Console Ports Keyboard 1 x USB Type A Female
(Black; rear panel)
Video 1 x DVI-I Female (White)
Mouse 1 x USB Type A Female
(Black; rear panel)
Speakers 2 x Mini Stereo Jack Female
(Green; 1 x front panel; 1 x rear panel)
Microphone 2 x Mini Stereo Jack Female
(Pink; 1 x front panel; 1 x rear panel)
KVM Ports Keyboard / Mouse 4 x USB Type B Female (White)
Video 4 x DVI-I Female (White)
Speakers 4 x Mini Stereo Jack Female (Green)
Microphone 4 x Mini Stereo Jack Female (Pink)
Power 1 x DC Jack
USB Hub USB Hub
Switches Selected 4 x Pushbutton
LEDs On Line / Selected 4 (Orange)
USB Link 4 (Green)
Emulation Keyboard/Mouse USB
Video 1920 x 1200@ 60Hz; DDC2B
Scan Interval 1–99 secs. (5 secs. default)
Power Consumption DC5.3V, 10.7W
Environment Operating Temp. 0 – 50°C
Storage Temp. -20 – 60°C
Humidity 0-80% RH, Non-condensing
Physical Properties Housing Metal
Weight 0.94 kg
Dimensions ( L x W x H ) 27.00×8.80×5.55cm

  • 1x CS1764A USB 2.0 DVI KVMP™ Switch
  • 4x Custom KVM Cable Sets (DVI-D)
  • 1x Power Adapter
  • 1x User Instructions
