CE820 Aten HDBaseT HDMI 2.0 KVM Extender (4K @ 100m)

£775.00 inc VAT

Aten CE820 USB 2.0 HDBaseT 4K HDMI  extender extends video, audio, USB, RS232 and Ethernet signals via a single CAT6 cable. It features enhanced bit error detection and correction to resist signal interference during high-quality video transmissions, EDID Buffer for smooth power-up and the highest quality display, status detection and LED indication for HDBaseT™ signal transmission on remote unit, HDBaseT™ Standard mode up to 4K @ 100 m (Cat 6 / 6a),  HDBaseT™ Long-Reach mode up to 1080P @ 150 m and it is HDMI (3D, Deep Color, 1080P, 4K); HDCP 2.2 Compatible. NEW

Data Sheet

Manual

SKU: CE820 Categories: , , , , , , , , , Tags: , , , ,

Description

The ATEN CE820 USB HDMI HDBaseT™ 2.0 KVM Extender integrates the latest HDBaseT™ 2.0 technologies to deliver 4K HDMI video, stereo audio, USB, Ethernet, and RS-232 signals up to 100 meters using single Cat6 / 2L-2910 Cat 6 cable. The HDBaseT™ 2.0 guarantees the most reliable transmission on the market as well as enables the long-reach capability that extends full HD 1080P signals up to 150 meters. With an easy cable installation supporting various signals, the CE820 is ideal for applications where convenient remote access is required – such as transportation control centers, medical facilities, industrial warehouses, and extended workstations.

  • Supports HDBaseT™ 2.0 technology
    • Extends video, audio, USB, RS-232, and Ethernet signals via a single Cat6 / 6a cable / 2L-2910 Cat 6 cable
    • Enhanced bit error detection and correction to resist signal interference during high-quality video transmissions
    • Status detection and LED indication for HDBaseT™ signal transmission on remote unit
  • EDID Buffer for smooth power-up and the highest quality display
  • HDMI (3D, Deep Color, 1080P, 4K); HDCP 2.2 Compatible
  • Long distance with superior video quality
    • HDBaseT™ Standard mode up to 4K @ 100 m (Cat 6 / 6a)
    • HDBaseT™ Long-Reach mode up to 1080P @ 150 m
  • Long Reach mode switch – switches between HDBaseT™ Standard and Long Reach modes in a snap
  • Supports individual 2-channel stereo audio and USB 2.0 full speed ports
  • Supports PC wakeup function via single pushbutton
  • Built-in 8KV / 15KV ESD protection (Contact voltage 8KV; Air voltage 15KV)
Function CE820L CE820R
Connectors
Console Ports N/A 1 x HDMI Female (Black)
3 x USB Type A Female
1 x Mini Stereo Jack Female (Green)
1 x Mini Stereo Jack Female (Pink)
1 x RJ-45 Female (Black)
KVM Ports 1 x HDMI Female (Black)
1 x USB Type B Female (White)
1 x Mini Stereo Jack Female (Green)
1 x Mini Stereo Jack Female (Pink)
1 x RJ-45 Female (Black)		 N/A
RS-232 1 x DB-9 Female (Black) 1 x DB-9 Male (Black)
Power 1 x DC Jack with locking 1 x DC Jack with locking
Unit To Unit 1 x RJ-45 Female (Black) 1 x RJ-45 Female (Black)
LEDs
Power 1 (Green) 1 (Green)
Link 1 (Orange) 1 (Orange)
Video Output N/A 1 (Orange)
Switches
Long Reach Mode Switch 1 x Slide Switch 1 x Slide Switch
Firmware Upgrade 1 x Slide Switch 1 x Slide Switch
Pushbuttons
Wakeup button N/A 1 x Push button
Video Up to 4K@90m (Cat 5e) / 100m (Cat 6/6a/ATEN 2L-2910 Cat6)
1080P@100m (Cat 5e/6/6a)
*4K supported:
4096 x 2160 / 3840 x 2160 @ 60Hz (4:2:0);
4096 x 2160 / 3840 x 2160 @ 30Hz (4:4:4)		 Up to 4K@90m (Cat 5e) / 100m (Cat 6/6a/ATEN 2L-2910 Cat6)
1080P@100m (Cat 5e/6/6a)
*4K supported:
4096 x 2160 / 3840 x 2160 @ 60Hz (4:2:0);
4096 x 2160 / 3840 x 2160 @ 30Hz (4:4:4)
Power Consumption DC5V:5.37W:40 DC5V:5.37W:40
Environmental
Operating Temperature 0–40°C 0–40°C
Storage Temperature -20–60°C -20–60°C
Humidity 0–80% RH, Non-condensing 0–80% RH, Non-condensing
Physical Properties
Housing Metal Metal
Weight 0.65 kg ( 1.43 lb ) 0.63 kg ( 1.39 lb )
Dimensions (L x W x H) 18.20 x 12.19 x 2.87 cm
(7.17 x 4.8 x 1.13 in.)		 18.20 x 12.19 x 2.87 cm
(7.17 x 4.8 x 1.13 in.)
Note For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format.

  • 1x CE820L USB HDMI HDBaseT 2.0 KVM Extender (Local Unit)
  • 1x CE820R USB HDMI HDBaseT 2.0 KVM Extender (Remote Unit)
  • 1x HDMI KVM Cable Set (HDMI, USB, Audio; 1.8m/6ft)
  • 2x Power Adapters
  • 2x Mounting Kits
  • 8x Foot Pads
  • 1x User Instructions
