ALIP AdderLink PS2 USB & VGA Single KVM Over IP

£834.00 inc VAT

Adder ALIP PS2 / USB & VGA Single KVM Over IP gives full control even during boot up, BIOS level or computer crash states. The ADDERLink IP will work even if the controlled devices are not. It employs enterprise grade security (using AES 128 bit encryption and RSA 2048 bit public key authentication) as standard, the ADDERLink IP is further enhanced by the use of Real VNC, allowing for the creation of ciphered user communications. It also allows for the integration of power switching devices that can be control through the user interface.

Data Sheet

Manual

Description

High Speed KVM over IP. Designed jointly with Real VNC the ADDERLink ALIP provides multi platform remote access to computers and servers in data centers & remote offices.

The ADDERLink ALIP is also ideal to connect to any analog KVM switch adding reliable KVM over IP functions. Providing remote Keyboard, Video and Mouse access via IP to your current KVM switch, the ADDERLink ALIP allows management of computers from anywhere in the world securely and remotely via the Internet, dial-up link or corporate network.

The ADDERLink ALIP doesn’t need any software to be loaded on your servers and is easy to set up and use. The ADDERLink ALIP supports the Real VNC client software that, unlike HTTPS web browsers, is specifically designed for secure, high performance KVM over IP applications. The ADDERLink ALIP integrates with your existing KVM infrastructure for a cost effective global management tool.

  • Independent operation
  • High video performance
  • Enterprise grade security using AES-128 bit encryption and RSA 2048 bit public key authentication.
  • User management: ALIP allows up to 16 user profiles with defined user access rights
  • Power control

Video resolutions

Supports standard PC, Sun and Mac video modes up to resolutions of 1600×1200 with scalable viewer

Hardware compatibility

Supports PC, RS/6000, Alpha and SGI computers using PS/2 or Sun (USB and 8-pin styles) and Mac (USB) when using the appropriate CCUSB/ CCSUN interface cables. Compatible with most KVM switches.

O/S compatibility

All known software and operating systems including Windows (all), DOS, Linux, Unix, BSD, Sun OS, Solaris, Mac OS, NetWare etc.

ADDERLink IP to KVM/computer connection

Video: HDD15

Keyboard/Mouse: MiniDin6. 1m 3-in-1 cable supplied

Local console

Video: HDD15

Keyboard/Mouse: MiniDin6

Connections

Ethernet: RJ45 10/100 autosensing

Serial: 2 x DB9

Physical design

1U compact case, robust metal construction

198mm/7.92″ (w), 44mm/1.76″ (h),

120mm/4.8″ (d), 0.75kg/1.65lbs

1 per 1U or 2 per 1U rack mount kits available

Power supply

100-240VAC, 50-60Hz

Operating temperature

0 – 40 deg C (32 to 104 deg F)

Approval

CE, FCCs

Order Codes

ALIP-XX

XX= Mains Lead Country Code:

UK = United Kingdom

US = United States

EURO = Europe

AUS = Australia

Additional accessories

Single unit rack brackets (includes four screws): RMK-ALIP

Double unit rack brackets (includes twelve screws): RMK-ALIP-DUAL

KVM cables (one set per connected computer): VKVM-XM (where X is the cable lengths in meters: 1, 2, 5 or 10)

CCUSB converter (required to connect with computers that use a USB port to connect their keyboard and mouse): CCUSB-XM (where X is the cable lengths in meters: 2, 5 or 10)

CCSUN converter (required to connect SUN computers that use a mini-DIN port to connect their keyboard and mouse): CCSUN-XM (where X is the cable lengths in meters: 2, 5 or 10)

PS/2 to AT -style keyboard converter: VSA3

PS/2 to 9-pin serial mouse converter: VSA1

Independent operation

Gives full control even during boot up, BIOS level or computer crash states. The ADDERLink IP will work even if the controlled devices are not.

High video performance

The ADDERLink IP can use a standard web browser but for superior graphical performance Real VNC is used. Free of the limitations of HTTPS, Real VNC greatly enhances video performance.

Security

Employing enterprise grade security (using AES 128 bit encryption and RSA 2048 bit public key authentication) as standard, the ADDERLink IP is further enhanced by the use of Real VNC, allowing for the creation of ciphered user communications.

User management

Knowing who does what and when is crucial for any remote access service. The ADDERLink IP can create up to 16 user profiles each defines user access rights. Each user’s activity is recorded and time stamped. The resulting log can be exported for historical review.

Power control

When attached computers crash or require resetting often the only solution is to power them off and back on again. The ADDERLink IP allows for the integration of power switching devices that can be control through the user interface.
